Photonics & electro-optic test systems

Instruments & Systems

Laser beam profilers, power meters, production testers and high-voltage drivers — designed, built and calibrated by IZAK engineers in Israel.

Product lines

Choose a product line

Each line is engineered in-house, from optics and electronics to software. Every system can be configured to your wavelength, power and integration needs.

Laser Beam Profilers

01Flagship line

Laser Beam Profilers

Beam analysis from 250 nm to 12 µm — packaged, OEM board-level or software-only.

  • Five spectral families, UV to LWIR
  • Live 2D/3D profiling, Pass/Fail and reports
  • API for production and OEM integration
35 models · 6 families
View family Request a quote
Power Meters & Radiometers

02Laser power & radiometry

Power Meters & Radiometers

Parallel power, spectral and temporal measurement for high-power lasers.

  • 5 fiber-coupled channels, 200 nm – 20 µm
  • Up to 50 W per channel
  • Radiometers linear up to 5 MHz
3 systems
View line Request a quote
IZAK Scientific production test systems

03Production test

Production Testers

Automated Pass/Fail stations for optical and thermoelectric components.

  • TEC verification before assembly
  • LED colour and position recognition
  • Fiber ferrule inspection, 4 automated tests
3 systems
View line Request a quote
Pulsed Xenon Light Sources

04Light sources

Pulsed Xenon Light Sources

UV–VIS–IR pulsed xenon modules, UV disinfection and lamp-ageing consoles.

  • 500 – 850 V in 8 steps, 0.2 – 2 Hz
  • Up to a few J per pulse
  • Ageing up to 100 pulses/s, 1 – 5 lamps
3 systems
View line Request a quote
High Voltage Switcher

05Electro-optic drivers

High Voltage Switcher

Fast HV switching for Pockels cells, Q-switching and pulse picking.

  • 0 – 15 kV output, rise time < 5 ns
  • 100 kHz continuous, 3 MHz burst
  • Output jitter < 500 ps
1 system
View line Request a quote
QuantumAlign NLO Stage

06Optomechanics

QuantumAlign NLO Stage

Kinematic crystal stage for nonlinear-optics and quantum photonics setups.

  • X‑Y translation with tip and tilt
  • Integrated high-voltage output
  • Optional thermal regulation
1 system
View line Request a quote

Flagship · Laser Beam Profilers

One platform, UV to LWIR

The same IZAK measurement software, Test and Pass/Fail mode and API across every detector — as a packaged system, an OEM board-level engine or software-only.

Explore the platformConfiguration guide
UV‑VIS‑NIR laser beam profiler

UV‑VIS‑NIR

300 – 1100 nm

8 models
  • 3.6 – 22.4 mm active width
  • 1.2 – 67.1 MP

SKU 31001 – 31008

View family Quote
SWIR laser beam profiler

SWIR

400 – 2050 nm

6 models
  • 2.5 – 10.2 mm active width
  • 0.3 – 5.2 MP

SKU 32001 – 32006

View family Quote
MWIR laser beam profiler

MWIR

1.5 – 5.7 µm

12 models
  • Cooled detectors, 75 – 1004 Hz
  • 0.08 – 2.95 MP

SKU 33001 – 33012

View family Quote
LWIR laser beam profiler

LWIR

7.7 – 12 µm

3 models
  • Thermal-IR and CO₂ lasers
  • 5.7 – 15.4 mm active width

SKU 34001 – 34003

View family Quote
OEM board-level laser beam profiler

OEM board-level

VIS – NIR

6 models
  • 4 global-shutter models for pulsed lasers
  • USB 3 powered, from 29 × 29 mm

SKU 35001 – 35006

View family Quote
Software-only laser beam profiler

Software-only

Any supported camera

Software licence
  • IZAK analysis, Test and reports
  • API for automation

SKU On request

View family Quote

Selection guide

Three answers, one starting configuration

A starting point only. Final optics, attenuation and packaging are confirmed in engineering review before any quotation.

Rule of thumb: recommended active width ≥ 1.25 × beam diameter.

1 · Wavelength band

2 · Beam diameter at the sensor

3 · Where it will run

Starting configuration

Family
Choose a band
Sensor width
Choose a beam size
Delivery model
Choose where it runs
Suggested models
—
Request this configuration Open full selector

Suggested models are highlighted in the comparison table below.

Compare all models

35 of 35 models

Laser beam profiler models with spectral range, active width and resolution
SelectModelFamilySpectral range
31001 Compact VIS‑NIR UV‑VIS‑NIR 0.4 – 1.0 µm 3.6 mm 1.2 MP
31002 Compact Broadband UV‑VIS‑NIR 0.3 – 1.1 µm 4.9 mm 1.3 MP
31003 Compact High Resolution UV‑VIS‑NIR 0.3 – 1.1 µm 5.6 mm 2.0 MP
31004 Mid-Size Performance UV‑VIS‑NIR 0.3 – 1.1 µm 9.8 mm 5.3 MP
31005 Large-Area High Resolution UV‑VIS‑NIR 0.3 – 1.1 µm 20.5 mm 31.4 MP
31006 Large-Area Very High Resolution UV‑VIS‑NIR 0.35 – 1.1 µm 20.5 mm 44.4 MP
31007 Ultra-High Resolution UV‑VIS‑NIR 0.35 – 1.05 µm 20.5 mm 67.1 MP
31008 Wide-Area Ultra-High Resolution UV‑VIS‑NIR 0.3 – 1.1 µm 22.4 mm 65 MP
32001 SWIR Compact SWIR 400 – 1760 nm 2.5 mm 0.3 MP
32002 SWIR Standard SWIR 400 – 1760 nm 5.2 mm 1.3 MP
32003 SWIR High Resolution SWIR 400 – 1760 nm 5.3 mm 3.2 MP
32004 SWIR Large-Area SWIR 400 – 1760 nm 7.1 mm 5.2 MP
32005 Extended SWIR FastFast SWIR 400 – 2050 nm 10.2 mm 0.3 MP
32006 NIR‑SWIR FastFast SWIR 900 – 1700 nm 10.2 mm 0.3 MP
33001 MWIR Standard75 Hz MWIR 3.7 – 4.8 µm 7.7 mm 0.08 MP
33002 MWIR High-Speed481 Hz MWIR 3.7 – 4.8 µm 7.7 mm 0.08 MP
33003 Broadband MWIR75 Hz MWIR 1.5 – 5.7 µm 15.4 mm 0.33 MP
33004 Broadband MWIR151 Hz MWIR 1.5 – 5.7 µm 15.4 mm 0.33 MP
33005 Broadband MWIR232 Hz MWIR 1.5 – 5.7 µm 15.4 mm 0.33 MP
33006 Ultra-Fast MWIR1004 Hz MWIR 1.5 – 5.5 µm 12.8 mm 0.33 MP
33007 High-Resolution MWIR MWIR 1.5 – 5.5 µm 10.2 mm 1.3 MP
33008 Fast MWIR622 Hz MWIR 1.5 – 5.5 µm 10.2 mm 0.33 MP
33009 High-Resolution MWIR180 Hz MWIR 1.5 – 5.5 µm 10.2 mm 1.3 MP
33010 MWIR HD MWIR 3.5 – 4.8 µm 8.6 mm 0.92 MP
33011 MWIR Ultra-HD MWIR 3.6 – 4.9 µm 15.4 mm 2.95 MP
33012 Compact MWIR, cost-effective MWIR 1.5 – 5.7 µm 9.6 mm 0.33 MP
34001 LWIR Compact LWIR 8 – 12 µm 5.7 mm 0.3 MP
34002 LWIR Large-Area LWIR 8 – 12 µm 12.3 mm 1.3 MP
34003 LWIR Wide-Area LWIR 7.7 – 10.2 µm 15.4 mm Per application
35001 OEM LBP 1.6 MP GlobalGlobal · 235 fps OEM board-level VIS – NIR 5 mm 1.6 MP
35002 OEM LBP 5.1 MP GlobalGlobal · 49 fps OEM board-level VIS – NIR 6.77 mm 5.1 MP
35003 OEM LBP 2.3 MP GlobalGlobal · 101 fps OEM board-level VIS – NIR 5.76 mm 2.3 MP
35004 OEM LBP 12.4 MP GlobalGlobal · 32 fps OEM board-level VIS – NIR 11.31 mm 12.4 MP
35005 OEM LBP 5 MP CWRolling · CW only OEM board-level VIS – NIR 5.7 mm 5 MP
35006 OEM LBP 5 MP CW, bare boardRolling · CW only OEM board-level VIS – NIR 5.7 mm 5 MP

No model matches. Describe your laser and we will configure one.

Tick one or more models to request a combined quote.

0 models selected

Request a quote for selection

Test, measurement & electro-optics

More IZAK systems

· Built to order and configurable — tell us your application and we recommend the right setup.

Custom configuration

Not finding the exact instrument?

Most IZAK systems are adapted to the customer’s wavelength, power, interface and test flow. Describe your application and an engineer will propose a configuration.

Describe your application

No system matches your search. Tell us what you need to measure — many IZAK systems are custom-built.

Engineering services

Need something that is not in the catalog?

Our optical and electro-optical engineers design custom measurement systems, test stations and control software — from feasibility study to a calibrated, documented system.

Explore engineering servicesTalk to an engineer
  • Optical and electro-optical system design
  • Automated production test stations
  • LabVIEW, FPGA and control software
  • Custom detectors, optics and attenuation
  • Integration through API and DLL
  • Calibration and test documentation

ISO 9001:2015

Certified quality management for design and production.

Concept to calibrated system

Optics, electronics, software and calibration under one roof.

Made in Israel

Designed and built in Atlit, with direct access to the team.

Engineering support

Talk to the engineers who built the system, before and after delivery.
